Honeywell CT37 Handheld Computer Features
The CT37 delivers a lightweight, user-friendly design that is built on the Mobility Edge™ platform, ensuring continuous productivity for front-line workers in retail, logistics, and healthcare.
The Mobility Edge™ platform is a durable, stable, secure foundation for which businesses build solutions around. The CT37 features a future compatible architecture that protects your investment, with Android support out to A18.
The housings on the CT37 are disinfectant ready and designed to withstand multiple cleanings from a variety of harsh cleaners. The housings stand up to multiple cleanings an hour by 34 different chemicals.
The CT37 is equipped with the latest 5G and Wi-Fi 6E technology, keeping you connected indoors and outdoors. 5G keeps mobile workers connected with the highest bandwidth and lowest latency available, reducing downtown and increasing productivity. The CT37 supports private 5G, CBRS, and Wi-Fi 6E, ensuring front-line workers stay connected.
Combined with powerful Honeywell software such as Operational Intelligence, Smart Talk unified communications and Smart Pay contactless payment, the CT37 is an ideal platform for users in retail, healthcare and transportation and logistics to build effective solutions.
With its hot-swappable battery feature, the CT37 eliminates interruptions for battery replacement, making it possible for extended operational use without downtime.
The CT37 also includes a secure element (SE) for preventing digital threats, adding a layer of physical security to the device. It ensures that sensitive information processed by applications on the SE is insulated and secured against unauthorized access.
Honeywell CT37 Handheld Computer Specifications
Features
Application
-
- Retail, Transportation & Logistics, Field Operations and Healthcare
For Use With
Housing Grade
-
- Disinfectant Ready Housing
Features
-
- Compatible with Universal Dock
Camera
-
- 13-megapixel color rear camera
-
- 8-megapixel color front camera
Dimensions
Overall Dimensions
-
- 167.4 mm x 76.0mm x 12.6mm (6.6 in x 3.0 in x 0.5 in)
Scanning Specifications
Decode Capability
-
- Honeywell FlexRange™ XLR S0803
-
- Standard Range Engine S0703 (1D/2D barcode symbologies)
Network
WWAN Specifications
-
- 4G-LTE DL CAT-18: ~800 Mbps
-
- 4G-LTE UL CAT-15: ~200 Mbps
-
- 5G FR1: Bands 1, 2, 3, 5, 7, 8, 12, 13, 14, 20, 25, 26, 28, 29, 30, 38, 40, 41, 48, 66, 71, 77, 78, 79
-
- 5G NSA-DL: ~2500 Mbps, UL: ~1050 Mbps
-
- 5G SA-DL: ~2300 Mbps, UL: ~1050 Mbps
-
- Global bands support, device certified with GCF-PTCRB, ATT, TMO, VZW
-
- LTE: Bands 1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 28, 29, 30, 38, 39, 40, 41, 42, 43, 48, 66, 71
WLAN Specifications
-
- Data rates: 2.4GHz: 802.11b/g/ax – 20MHz up to 286.8Mbps; 5GHz: 802.1/n/ac/ax -20MHz, 40MHz, 80MHz, 160MHz up to 2882Mbps; 802.11ax- 20MHz, 40MHz, 80MHz, 160MHz up to 2882Mbps.
-
- IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v/w/mc/ax, 2×2 MU-MIMO; Triband (2.4GHz, 5GHz, 6GHz); Wi-Fi 6E (801.11ax); Dual Band Simultaneous (DBS); IPv4, IPv6
-
- Supported EAP: TLS, PEAP, TTLS, PWD, LEAP, CCX compatible.
-
- WLAN Security: Enhanced open (OWE), WEP, WPA/WPA2/WPA3 (Personal and Enterprise)
-
- Wi-Fi certified; Wi-Fi 6E certified.
GPS Specifications
-
- GPS, GLONASS, Galileo, Beidou, QZSS, NavIC, Dual band GNSS-Concurrent L1/G1/E1/B1 with L5/E5a/BDSB2a, a-GPS, Supports XTRA
Bluetooth Specifications
-
- V5.3 Bluetooth and BLE; 2nd BLE
RFID Specifications
-
- Integrated NFC reader, compliant with ISO/IEC 1443A, ISO/IEC 1443 B, ISO/IEC 15693 (ICode), MIFARE 1K/4K, MIFARE DESFire, Sony FeliCa, ISO/IEC 18092 (Type F), Contactless payment support, ECP 1.0 and ECP 2.0.
Computer Wireless Communication
Software & Firmware
Operating System
-
- Each Android version guaranteed from Android 14 to 18, subject to technical feasibility confirmed by Qualcomm
Memory & Data
Memory
-
- 8GB DDR5 RAM, 128GB UFS 3.1 Flash
Hardware
Scan Engine Range
-
- Standard Range and FlexRange
Display Resolution
-
- Full High-Definition (2280 x 1080)
Scan Engine Type
Scan Engine Model
-
- Honeywell S0703 Slim Imager ; Honeywell FlexRange™ XLR S0803
Processor
-
- Qualcomm QCS4490 or QCM4490 octa-core, up to 2.4GHz
Display Size
-
- Gorilla Glass™ Victus™ , 6-inch
Electrical
Battery Capacity
Battery Types
Battery Type
Environmental
Storage Temperature Range
-
- -30° to 70°C (-22°F to 158°F)
Operating Temperature
-
- -10° to 50°C (14°F to 122°F)
Operating Humidity
-
- 5% to 95% (non-condensing)
Standards & Approvals
Drop Specifications
-
- Multiple 1.2m (4ft) drops to concrete at operating temperature per MIL-STD 810H
-
- Multiple 1.5m (5ft) drops to concrete at operating temperature wtih boot per MIL-STD 810H
-
- Multiple 1.5m (5ft) drops to concrete at room temperature per MIL-STD 810H
-
- Multiple 1.8m (6ft) drops to concrete at room temperature wtih boot per MIL-STD 810H
Protection Ratings
Tumble Specifications
-
- 550, 0.5m (1.6 ft) tumbles
-
- 550, 1.0m (3.3 ft) tumbles with protective boot
Others
Operating System Type
Camera Position
Platform
